Sold

Sandvik DE130 Diamond Core Drill

• Make: Sandvik
• Model: DE130
• Year: 2018 (Purchased New in 2021)
• Condition: Used Condition - Reported in Great Condition, Well Maintained
  • Recently Drilling at a Top Tier Mining Program and Passed all the Strictest Rig Inspections and Safety Audits
• Has HQ Upgraded Sandvik Head
  • New Factory Head Rebuild
• Mains Voltage: 460 Volt
  • Frequency: 60Hz
• Drill is Ready to be Dispatched onto a Long-Term Project
• Stored in a Covered and Heated Shop
•
  View Spec Sheet Below


• General Model Technical Data
  • Depth Capacity:
    • (N): 815m (2,674ft)
    • (H): 400m (1,312ft)
    • (B): 800m (2,624ft)
    • (WL56): 1,200m (3,936ft)
  • Lift Capacity: 1280m (4200ft) with WL56 Rod
  • Rotation Unit N Size: 77mm (3in)
  • Rotation Unit H Size: 103mm (4in)
  • Torque:
    • Max Torque: (N High Speed):  550Nm (406 lbf/ft)
    • Max Torque (N High Torque): 800Nm (590 lbf/ft)
    • Max Torque (H): 940Nm (693 lbf/ft)
  • Speed:
    • Max RPM (N High Speed): 1,600 RPM
    • Max RPM (N High Torque): 1,100 RPM
    • Max RPM (H): 1,100 RPM
  • Feed Force: 46.1 kN /4.7 T (10,360 lbf)
  • Feed Rate, Rod Running Max: 1.1m/s (43in/s)
  • Feed Rate, Drilling Max: 0.04m/s (1.5in/s)
  • Pull Force: 61.5 kN /6.3 T (13,820 lbf)
  • Feed Length (Stroke): 1,700mm (5ft 7in)
  • Total Length: 3,065mm (10ft 1in)
  • Power Unit: 55kW (75HP)


• Location: Central USA
