• Dimensions:
  • Width over tracks: 8.2 ft in (2500 mm).
  • Height to top of cab: 10.2 ft in (3095 mm).
  • Length of track on ground: 10.2 ft in (3117 mm).
  • Ground clearance: 1.3 ft in (394 mm).
  • Length w/o blade: 12.3 ft in (3740 mm).
• Undercarriage:
  • Track gauge: 7.1 ft in (2160 mm).
  • Standard shoe size: 33.1 in (840 mm).
• Specification:
  • Engine:
    • Make: Caterpillar
    • Model   C6.6 ACERT.
    • Net power: 150 hp (112 kw).
    • Power measured @ 2000 rpm.
    • Displacement: 402.8 cu in (6.6 lL).
    • Number of cylinders: 6.
  • Operational:
    • Operating weight: 39222 lb (17791 kg).
    • Fuel capacity: 79 gal (299 l).
    • Cooling system fluid capacity: 9.2 gal (35 l).
    • Hydraulic fluid capacity: 7.8 gal (29.5 l).
    • Final drives fluid capacity: 1.8 gal (7 l).
    • Operating voltage: 24 V.
    • Alternator Supplied Amperage: 95 amps.
  • Transmission:
    • Type: Hydrostatic.
    • Number of forward gears: 5.
    • Number of reverse gears: 5.
    • Max speed - forward: 6.2 mph (10 km/h).
    • Max speed - reverse: 7.2 mph (11.6 km/h).
  • Undercarriage:
    • Ground pressure: 4.8 psi (33.2 kpa).
    • Ground contact area: 8122 in2 (5.2 m2).
    • Standard shoe size: 33.1 in (840 mm).
    • Number of shoes per side: 46.
    • Number of track rollers per side: 8.
    • Track gauge: 7.1 ft in (2160 mm).
  • Standard blade:
    • Width: 13.4 ft in (4080 mm).
    • Capacity: 4.1 yd3 (3.2 m3).
  • Dimensions:
    • Length w/o blade: 12.3 ft in (3740 mm).
    • Width over tracks: 8.2 ft in (2500 mm).
    • Height to top of cab: 10.2 ft in (3095 mm).
    • Length of track on ground: 10.2 ft in (3117 mm).
    • Ground clearance: 1.3 ft in (394 mm).
