• CFM: 1600.
• Rated Pressure: 150 psig (10 Bar).
• Pressure Range: 85-150 psig (5.8-10 Bar).
• Mounting options:
  • Tri-axle.
  • Four-wheel steerable.
  • Less running gear.
• Engine: Tier 3 Caterpillar 540 hp (403 kW).
• Designated Model:

  • Tri-Axle Mount:
    • Weight: 16350 lbs (7416 kg.)
    • Length: 240 in (6096 mm).
    • Length (drawbar): 179 in (4547 mm).
    • Width (canopy): 88 in (2235 mm).
    • Height (cannopy): 92 in (2337 mm).
    • Track width: 77 in (1956 mm).
    • Tire Size (load range): ST 235/80R16 (E).
  • 4-Wheel Mount:
    • Weight: 16020 lbs (7267 kg.)
    • Length: 244 in (6198mm).
    • Length (drawbar): 179 in (4547 mm).
    • Width (canopy): 88 in (2235 mm).
    • Height (cannopy): 101 in (2565 mm).
    • Track width: 78 in (1981 mm).
    • Tire Size (load range): 8.25 X 15 TR (F).
  • Without Running Gear:
    • Weight: 15250 lbs (6917kg).
    • Length (drawbar): 179 in (4547 mm).
    • Width (canopy): 88 in (2235 mm).
    • Height (cannopy): 83 in (2108 mm).
