StokkerMill IM 30 Impact Mills

  • Model: IM 30
    • Quantity= 3

  • Mill Dimensions:
    • 30" Diameter x 19" Long

  • Hammers
    • 16" Long x 2" Thick
    • Quantity= 4

  • Screens
    • Spacing Size: 3/4" Long x 3/16" Wide Gap

  • Motor
    • Elvem TEFC 3 Phase
    • 54 kW @ 60Hz (45 kW @ 50Hz)
    • 480/830 VAC @ 60 Hz (400/690 VAC @ 50 HZ)
    • 1760 RPM @ 60 Hz (1470 RPM @ 50 Hz)

  • Side Infeed Hopper
    • 7" x 6" Infeed with 8 Bolt Flange
    • 20" Long x 15" Wide x 23" High

  • Bottom Discharge Hopper
    • 4" Diameter Discharge
    • 24" Long x 18" Wide x 14" High
    • Quantity= 3

  • Electric Control Boxes
    • Quantity= 2
    • Indoor Digital Interface
      • Controls Direction
      • Start/Stop Button
      • Emergency Stop Button
    • Square D 50 Amp Breaker
      • Square D NHDF36150
    • Botter Control Transformer
      • 300 VA
      • Primary: 400-480 Volts
      • Secondary: 0-110 Volts
    • Hour Meter
      • 840 Hours
    • Power Indicator Light on Top of Can

  • Mounted on Common Frame
    • Made From 3" x 4.5" Tube

  • Crate of Mill Liner Screens and Upper Wear Bars
    • 9 Liners (Screens)

  • Located in British Columbia, Canada
