• Rotation Speed: 0-200 rpm.
• Hydraulic Pressure: 2130 psi / 150 kg / cm2.
• Type: Cummins 6CT8.3.
• Rated Horse Power: 215 hp / 159 kw.
• Operating Speed: 2350 rpm.
• Max. Horizontal Boom Swing: 30° right / 34.6 left.
• Max. Vertical Boom Movement: 51° up / 15° down.
• Max. Guide Swing: 48° right / 40° left.
• Max. Guide Dump: 180°.
• Guide Extension: 4 ft / 1219 mm.
• Overall Guide Length: 23 ft-8 in. / 7214 mm.
• Compressor Type: Ingersoll-Rand Rotary Screw.
• Compressor Volume: 250 cfm / 7 m3 / min.
• Compressor Pressure: 140 psig / 9.9 kg / cm2.
• Gradability: 35°(70%).
• Tram Speed: 2 mph / 3.3 km/h.
• Grouser Width: 12 in. / 305 mm.
• Steel length: 14 ft starter rod  / 4.27 m.
• Shipping Width: 8 ft / 2438 mm.
• Shipping Height: 9 ft-4 in. / 2845 mm.
• Overall Length: 19 ft-5 in. / 5918 mm.
• Ground Clearance: 18 in. / 457 mm.
• Fuel Capacity: 100 U.S. gal / 378 L.
• Automatic rod changer
• Hours: 5,279.
