Need this? Click here    Have one? Click here
  • #: Bank of 4.
  • Cell Dimensions: 12 in. x 12 in. x 12 in.
  • Includes: Dual paddle shafts and motors with reducers.
  • Dayton ¼ hp Motors:
    • Volts: 115.
    • RPM: 12.
    • Single Phase.
    • Gear reducer ratio: 144.5:1.
  • Premix Tank Dimensions:
    • 23 in. L x 8 in. W x 14 in. D.
    • US Electric ¾ hp Motor:
      • Volts: 230/460.
      • RPM: 1775.
      • TEFC.
  •  US Electric ¾ hp diffuser motors:
    • Volts: 230/460.
    • RPM: 1775.
    • TEFC.
    • Quantity: 4.
  • Fisher Controls Air Actuator:
      • Type: 657
      • Size: 40.
      • Max supply: 65.
      • Operating range: 3-15.
      • Travel: 1 1/8.
  •  Flotation Body Details
    • Type: ES.
    • Size: 2.
    • Seat: 416 SS.
    • Stem/Plug: 360SS/416 SS.
    • Port size: 2 5/16 in.
    • Rating: 150.
  • Overall Dimensions: 104 in. L x 48 in. W x 72 in. H.
