- #: Bank of 4.
- Cell Dimensions: 12 in. x 12 in. x 12 in.
- Includes: Dual paddle shafts and motors with reducers.
- Dayton ¼ hp Motors:
- Volts: 115.
- RPM: 12.
- Single Phase.
- Gear reducer ratio: 144.5:1.
- Premix Tank Dimensions:
- 23 in. L x 8 in. W x 14 in. D.
- US Electric ¾ hp Motor:
- Volts: 230/460.
- RPM: 1775.
- TEFC.
- US Electric ¾ hp diffuser motors:
- Volts: 230/460.
- RPM: 1775.
- TEFC.
- Quantity: 4.
- Fisher Controls Air Actuator:
-
- Type: 657
- Size: 40.
- Max supply: 65.
- Operating range: 3-15.
- Travel: 1 1/8.
-
- Flotation Body Details:
- Type: ES.
- Size: 2.
- Seat: 416 SS.
- Stem/Plug: 360SS/416 SS.
- Port size: 2 5/16 in.
- Rating: 150.
- Overall Dimensions: 104 in. L x 48 in. W x 72 in. H.
