• Fresh Water System:
    • Fresh water pump (Make/Model TBA).
    • 640' - PVC Yelomine 10 inch gasket fit pipe.
    • Water distribution system.
    • McCrometer ultra mag flowmeters.
    • 6' x 8' suction screen included.
    • Sump make-up water supply.
      • Automatic c/w electric valve and electronics.
    • RMS fabricated foot valve.
    • Suction hose - 12" suction hose complete with fittings.
    • Hydrocyclone sand separator (15 GPM).
      • Gland water supply for slurry pump to avoid manual clean up of water filter.



  • Derocker System.
    • Model D10AS (10' x 20').
    • High pressure intensity impact spray nozzles.
    • ITT Goulds 3196 XLTi Size: 6 x 8 x 13 pump fresh water booster pump.
    • Fittings, hoses, shutdowns, bypass line, valves and skid for booster pump.
  • Screening System:
    • 5' x 15' triple deck horizontal vibrating screen.
    • Feedbox and distributor for screen deck.
    • 5' x 15' triple deck screen spare parts and replacement screens.
    • Installed screens fitted on 5' x 15' triple deck screen.
    • Skid frame and sump for 5' x 15' triple deck screen.
    • Frame and stand for hydrocyclone.
  • Slurry System:
    • Slurry Pump:
      • 10 x 8 x 21 SRL-C slurry pump with O/H base and guard.
      • 100 hp electric motor and VFD complete with level controls for slurry pump.
    • Krebs Hydrocyclones complete with:
      • Bank of 6 - 10 " dia. Krebs hydrocyclones.
        • Hydrocyclone feed header/distributor with knife gate valves.
        • Overflow and underflow piping for Krebs hydrocyclones.
    • Overflow and underflow troughs for slurry handling.
  • RMS 6' and 3' Circular Jig Plant Recovery System:
    • 6' duplex circular jig plant complete with:
      • 2 6' Circular jigs.
      • Jig shot
      • Steady head tanks.
      • Sala Pump.
      • Frequency controllers for speed control.
      • 3' cleaner jigs.
      • Skid mounted.
    • Concentrate bins - 1 cubic meter each. (10)
      • Complete with overflow capture and lockable lids.
    • Hose and piping for plant slurry handling.
    • Walkways, platforms and handrails for jig plant.
  • Walkways and handrails for screen and hydrocyclones.
  • Sluice Recovery System:
    • 10' x 20' RMS-Ross Sluice.
  • Oversize Handling Conveyor:
    • (Used) Oversize tailings discharge conveyor - 24" x 40' long.
    • Cable stays for conveyor.
  • Electrical System:
    • 300+ KW generator set (Make/Model TBA).
    • Plant electrical.
  • Containers for shipping.
    • 5 - 40' certfied wind and water tight containers
Sold
