• Engine:
  • Make: Scania.
  • Model: DC 9.
  • Gross Power: 313.8 Hp / 234 Kw.
  • Displacement: 549.2 Cu / In 9 L.
  • Max Torque: 1069.5 Lb Ft / 1450 Nm.
  • Aspiration: Turbocharged.
  • Number Of Cylinders: 6.
• Dimensions:
  • Overall Length: 30.8 Ft In / 9400 Mm.
  • Overall Width: 9 Ft In / 2750 Mm.
  • Overall Height: 11.6 Ft In / 3550 Mm.
  • Ground Clearance: 1.9 Ft In / 576 Mm.
  • Dump Height: 17.6 Ft In / 5355 Mm.
  • Dump Ground Clearance: 2 Ft In / 610 Mm.
• Operational:
  • Fuel Capacity 84.5 Gal / 320 L.
  • Hydraulic System Fluid.
  • Capacity 36.5 Gal / 138 L.
  • Cooling System Fluid Capacity 9.5 Gal / 36 L.
  • Engine Oil Capacity 7.1 Gal 27 L.
  • Transmission Fluid Capacity 15.1 Gal / 57 L.
  • Operating Voltage: 24 V.
  • Alternator Supplied Amperage 100 Amps.
  • Tire Size: 23.5R25.
• Transmission:
  • Type: ZF 6 Wg 260 Dash 4 Electronically-controlled automatic.
  • Number Of Forward Gears: 6.
  • Number Of Reverse Gears: 3.
  • Max Speed: 31.7 Mph / 51 Km/h.
  • Total Loaded Weight: 100310.3 lb / 45500 kg.
