• Shank: 7/8 in. x 108 mm
• Weight: 40 kg
• Length: 585 mm
• Profile Height from Rod Center: 56 mm
• Rotation Rate: 0- 350 RPM Independent, Reversible Rotation
• Impact Rate: 80 Hz @ 150 Bar
• Rotation Torque: 90 Nm @ 120 Bar
• Hydraulic Requirements
  • Percussion Pressure: 120 - 150 Bar
  • Oil Flow: 60 - 70 L/Min @ 120 - 150 Bar
  •  Viscosity: Range: 60 - 30 CST
  • Air Flushing:
    • Air Consumption: 600 - 950 L/Min @3/5 Bar
    • Relief Valve Set: 7 Bar
    • Shank Lubrication: Standard
  • Water Flushing:
    • Water Consumption: 5 - 10 L/min
    • Water Pressure: 2 - 6 Bar
    • Air Consumption: 200 - 300 L/Min @ 3-5 Bar
  • Flushing Pipe Diameter: 5 mm
• Location: British Columbia, Canada
