Sold

Ludman 4440 Roll Compactor

Quantity: (2) Units Available

• Make: Ludman Industries
• Model: 4440
• Condition: New, Unused Condition
• Type: Double Roll Press Compactor
• Throughput Capacity: 140TPH
• Product Density: 1,089kg/m³
• Construction: Steel
• Roll Dimensions: 44in Dia. x 40in Long
• Max Roll Separating Force: 850 Tons
• Compactor Dimensions: 13ft Long x 12ft Wide x 19ft 4in Tall
• Drive: Electric Motors
  • Qty: 2 Per Compactor
  • Make: Siemens
  • Power Output: 800HP
• Screw Feeders:
  • Qty: 2 Per Compactor
  • Capacity: 140TPH
  • Drive: Siemens 75HP Electric Motor
  • Dimensions: 2.36m Long x 2.12m Wide x 4.15m Tall
• Hydraulic Power Unit:
  • Liquid Density: 900kg/m³ @15.6°C
  • Dimensions: 1.08m Long x 0.77m Wide x 0.81m Tall
• Gearbox Lubrication Unit:
  • Flow Rate: 29L/min
  • Dimensions: 2.87m Long x 1.54m Wide x 1.91m Tall
• Bearing Lube Unit:
  • Dimensions: 1.14m Long x 0.91m Wide x 1.73m Tall
• Shaft Guards


• Location: Europe

Optional VFD and Braking Resistor Package Sold Separately
