Gekko IPJ 2400 Inline Pressure Jig

• Make: Gekko Systems
• Model: IPJ 2400
• Condition: Used, Reported in Good Condition


• General Model Specifications:
  • Feed Flow Rate: 200m³/hr
  • Max Solids Feed Rate: 100TPH
  • Max Particle Size: 22mm
  • Concentrate Mass Recovery: 1-25TPH
  • Max Operating Pressure: 200kPa
  • Hutch Water Requirements: 25-120m³/hr
  • Water Supply Pressure: 350kPa
  • Pulse Rate: 50-250cy/min


• Drive: Electric Motor
  • Power Output: 3HP (2.2kW)
  • Voltage: 480 Volts
  • Frequency: 60Hz
  • Phase: 3-Phase


• Overall Dimensions:
  • Diameter: 2,426mm
  • Height: 3,164mm


• Location: Western USA
