• 3 drills included in package
  • One unit needs work or could be used as parts machine.
  • Rotary
    • Nominal Torque: 170 KNm (125,500 lbs/ft.)
    • Nominal Pull-Back/Pull-Down: 170 - 135 KN (38,250 - 30,375 lbs)
    • Unloading Speed: 150 rpm
    • Stroke: 4300 mm (14 ft.)
  • Winches
    • Main Winch Nominal Pullback: 140 KN (31,500 lbs)
    • Secondary Winch Nominal Pullback: 80 KN (18,000 lbs)
  • Engine
    • Brand CATERPILLAR
    • Model C7
    • Power: 186 KW @ 2100 rpm (250 HP @ 2100 rpm)
  • Hydraulic System
    • Hydraulic Oil Tank: 470 liters (124 gal)
    • Fuel Tank: 200 liters (53 gal)
  • Crawler
    • Length: 4,500 mm (14.75 ft.)
    • Shoes: 600 mm (2 ft.)
  • Weight: 33 ton (72,750 lbs)
  • Location: Eastern, USA
  • Contact for more information.
  • The HR 130 is a powerful compact rig that does not require disassembly for transporting from job to job. It is able to drill large diameters with augers and buckets, and can also be equipped with diverse kits which allow to drill with Continuous Flight Auger, Diaphragm walls, Down the Hole Hammers, and even Casing Oscillators.  The HR 130’s particularly modular conception allows easily and rapidly convertible depending on the drilling requirements, allowing the operator to carry out a wide variety of jobs which would otherwise require the use of different and expensive equipment. The HR 130 comes equipped with electronic depth counter, automatic levelling system, and air conditioning & heating system in order to better accommodate the operator.
