• Year: 2016
  • 3500 Hours
  • Serviced Monthly
  • Max Drilling Diameter
    • Uncased: 2200 mm
    • Cased: 2200 mm
    • Max Drilling Depth: 88 m
  • Dimension
    • Working Condition: 10770 mm long x 4800 mm wide x 23350 mm high
    • Transportation Conditions: 17410 mm long x 3500 mm wide x 3815 mm high
    • Overall Drilling Weight: 92 tons
  • Engine
    • Model: Cummins QSM11-C400
    • Rated Power: 298/2100 kW
  • Hydraulic System
    • Working Pressure: 354 MPa
  • Rotary Drive
    • Max Output: 280 kN.m
    • Rotary Speed: 5.5-21 r/min
    • Spin Off Speed: 90 r/min
  • Crowd Winch
    • Max Pull-Down Piston Push: 300 kN
    • Max Pull-Down Piston Pull: 300 kN
    • Max Pull-Down Piston Stroke: 16000 mm
  • Main Winch
    • Max Pulling Force: 260 kN
    • Max Single-Rope Speed: 60 m/min
    • Diameter of the Steel Wire Rope: 32 mm
  • Auxiliary Winch
    • Max Pulling Force: 80 kN
    • Max Single-Rope Speed: 65 m/min
    • Diameter of the Steel Wire Rope: 20 mm
  • Drilling Mast
    • Left/Right Inclination of Mast: 42464°
    • Front Inclination of Mast: 5°
    • Rotary Table Slewing Angle: 360°
  • Traveling
    • Max Traveling Speed: 1.5 km/h
    • Max Grade Ability: 35%
  • Crawler
    • Track Shoe Width: 800 mm
    • Distance Between Tracks: 3500-4800 mm
    • The Length of Crawler: 5052 mm
    • Average Ground Pressure: 102 kPa
  • Location: Middle East
