• Dimensions (H x W x D): 114 cm x 76 cm x 99 cm (45 in. x 30 in. x 39 in.).
• Speed Selection Range: 50 to 21,000.
• Speed Control Accuracy: ± 1% or 100 rpm, whichever is greater.
• Maximum Relative Centrifugal Force: 51,070 g.
• Temperature Selection Range: -20 to 40° C.
• Temperature Control Range: +2 to =40°C.
• Temperature Control Accuracy: ±1° C.
• Run Time Selection Range: 0 to 99 hr, 59 min or Hold.
• Ambient Temperature Range: 22
• Mass (Weight): 308 kg (680 lbs).
• Electrical Requirements.
  • Input Power (polyphase, 30 A): 220 V, 50 Hz.
  • Input Power (single phase, 30 A).
    • 240 V, 50 Hz .
      230 V, 60 Hz .
      220 V, 50 Hz .
      208 V, 60 Hz .
      200 V, 60 Hz.
  • Heat Output: 4 kW (13,500 Btu/h).
  • Location: British Columbia, Canada.
