• Bucket capacity: 6.5-8.6 m³; (8.5-11.0 yd³).
  • Major components
    • Diesel engine: Volvo TAD1361VE.
    • Engine output: 285 kW (388 hp) / 1900 rpm.
    • Transmission: Dana, 6422.
    • Axles: Dana, 53R300.
    • Tires: 29.5x29.
  • Tramming capacity: 17200 kg (38000 lb).
  •  Breakout force, lift: 343 kN (35000 kg); (77160 lb).
  • Breakout force, tilt: 289 kN (29450 kg); (64930 lb).
  • Weights
    • Operating weight: 44000 kg (97000 lb).
    •  Total loaded weight: 61200 kg (135000 lb).
  • Dimensions
    • Total length: 11120 mm (438").
    •  Max. width: 3000 mm (118").
    •  Height with canopy or cabin: 2750 mm (109").
    •  Ground clearance: 505 mm (20").
