Sandvik DD320 2 Boom Jumbo Drill ID: 411625


  • Model: DD320
  • Year: 2011
  • Hours: 12.028** 5048 and 165
  • S/N: A01286
  • Carrier: 1 x TC 6
  • Safety Canopy: 1 FOPS (ISO 3449)
  • Rock Drill: 2 x HLX5
  • Feed: 2 x TF 500-12
  • Boom: 2 x B 26 XLSF
  • Control Panel: 2 x THC 560
  • Powerpack: 2 x HP 555 (55,0 kW)
  • Air Compressor: 1 x CT 10
  • Shank Lubricating Device: 1 x KVL 10-2
  • Water Pump: 1 x WBP 2
  • Main Switch: 1 x MSE 20
  • Cable Reel: 1 x TCR 2E
  • Length: 12,520 mm
  • Width: 1,900 mm
  • Height
    • Canopy Down: 2,345 mm
    • Canopy Up: 3,195 mm
  • Weight: 19,400 kg
  • Tramming Speed
    • Horizontal: 12,0 km/h
    • 14% = 1:7 = 8°: 4,2 km/h
  • Max Grade Allowed: 25% = 1:4 = 14°
  • Noise Level
    • Operator's Platform: LpA = 102 dB
    • Emitted: LwA = 124 dB
