• Brand: IMEFY SPAIN.
  • Condition: New Unused.
  • Year of Manufacture: 2016.
  • Application: Power Transformer.
  • Basic Transformer Concept: Oil-immersed, hermetically sealed.
  • Number of Phases: 3-phase.
  • Rated Power: 2000 kVA.
  • Method of Cooling: ONAN.
  • Voltage Ratio - HV/LV1: 20000 / 400 V.
  • Voltage Regulation: Off-circuit tap changer.
  • Tapping Range: ± 2x2.5%.
  • Frequency: 50 Hz.
  • Connection: Dyn5.
  • No-load Losses: 2100 W.
  • Load Losses: 18000 W.
  • Standards: IEC 60076-1.
  • Temp. rise: 40ºC / 65 K / 60 K.
  • Insulation levels HV: 24 / 125 / 50 kV (Vmax / LI / AC).
  • Insulation levels LV: 1,1 / 20 / 10 kV (Vmax / LI / AC).
  • Material HV/LV: Aluminum /Aluminum.
  • Total Weight: 5000 kg.
