- Dimensions and Weight
- Weight: 170 kg
- Length without Shank Adapter: 1008mm
- Width Including Connectors: 251mm
- Height: 223mm
- Height over Drill Center: 88mm
- Rotation Motors
- Type: 05 0MS100/07 0MS160
- Rotation Range: 0-340/215 RPM
- Torque: 640/1000 Max Bar
- Working Pressure: 210 Max Bar
- Oil Consumption: 75 l/min
- Impact Ratings
- Impact Power: 18 kW Max
- Input Power to Rock Drill: 31 kW Max
- Hydraulic Pressure: 230 kW Max
- Flow Rate: 75-92 l/min
- Impact Frequency: 60 Hz
- Impact Energy: 330 Nm
- Rebuilt
- 2 Units Available
- Location: South Korea
