• Bank of 8.
• Vertical amps: 300.
• Horizontal amps: 1200.
• Bank 1:
  • Main infeed.
    • Qty: 1.
    • Westinghouse 800 amp interrupter breaker.
• Bank 2:
• 60 amp fusible disconnect – Qty: 1.
• 60 amp fuses – Qty: 2.
• 42 circuit breaker panel.
• Bank 3:
  • 30 amp fusible disconnect.
  • 25 amp fuses – Qty: 3.
• Bank 4:
  • Size 1 Starter (709 starter).
    • 30 amp disconnect.
    • 10 amp fuses – Qty: 3.
    • Overload: W36.
  • Size 2 starters (709 starter).
    • Qty: 3.
    • 30 amp fusible disconnect.
    • 6 – 30 amp fuses.
    • 3 – 10 amp fuses.
    • Overload: S
• Bank 5:
  • Size 1 starter.
    • Qty: 3.
    • 30 amp disconnects.
• Bank 6:
• Bank 7:
  • Size 1 starter.
    • 30 amp fusible disconnect.
    • 2 – 30 amp fuses.
    • Overloads: 2 – N32.
  • Size 5 starter.
    • ITE 600 amp interrupter breaker.
    • Built in 300:5 current transformers.
    • Overloads: 2 – W42.
• Bank 8:
  • Size 3 Starter.
    • Qty: 1.
    • 100 amp disconnect.
  • Size 1 starter.
    • 30 amp disconnect.
    • 3 – 10 amp fuses.
• Location: British Columbia, Canada.
