Rolls-Royce Engine details:

• 5587kW Engine X 2
• Make: Rolls-Royce(Norway)
• Manufacturing year: 2015
• Model:B32:40V12A
• Rated Power(Mechanical):5760kW
• Rated Power(Electrical):5587kW
• Number of Cylinders:12
• Engine speed:720
• Fuel: MDO
• Heavy duty type
• Turbocharged
• Water cooled
• Fuel consumption(g/kWh):184
• Lubricating oil consumption(g/kWh):0.8
• Cooling Water temp. engine outlet temperature:90 degree
• Certificated meet IMO Teir 2
• Size:6040mm x2712mmx4526mm(H)
• Weight Approx.:56ton
• Marine classfication:DNV /Offshore
• Ambient temperature:55 degree

• 4190kW Engine X 4
• Make: Rolls-Royce(Norway)
• Manufacturing year: 2015
• Model:B32:40L9A
• Rated Power(Mechanical):4320kW
• Rated Power(Electrical):4190kW
• Number of Cylinders:9
• Engine speed:720
• Fuel: MDO
• Heavy duty type
• Turbocharged
• Water cooled
• Fuel consumption(g/kWh):184
• Lubricating oil consumption(g/kWh):0.8
• Cooling Water temp. engine outlet temperature:90 degree
• Certificated meet IMO Teir 2
• Size:6943mm x2041mmx3899mm(H)
• Weight Approx.:46ton
• Marine classfication:DNV /Offshore
• Ambient temperature:55 degree

Generator 1:

• Make:ABB
• Manufacturing year: 2015
• 5587kW
• Voltage:6600V
• Current:611A
• Frequency:60HZ
• RPM:720
• Power factor:0.8
• Direction of rotating:CCW
• Size:3590mm x2490mm x3010mm(H)
• Weight:20.2ton

Generator 2:

• Make:ABB
• Manufacturing year: 2015
• 4190kW
• Voltage:6600V
• Frequency:60HZ
• Current:458A
• RPM:720
• Power factor:0.8
• Direction of rotating:CCW
• Size:3410mm x2240mm x3005mm(H)
• Weight:20ton

Heat Exchange:

• Coolant flow:19m3/hour
• Location: Offshore
