2019 CAT 336 Crawler Excavator

  • Make: Caterpillar
  • Model: 336
  • Year: 2019
  • Hours: 1,352
  • Condition: Used, Reported in Good Condition
  • Boom: Reach Boom 6.5m (21'4")
  • Stick: Reach Stick 3.9m (12'10")
  • Bucket: GDC 2.27m³ (2.97 yd³)
  • Counterweight: 14,990 Lbs.
  • Long Undercarriage with HD Rollers
  • Enclosed ROPS Cabin with AC
  • Backup Camera

  • Working Ranges And Forces:
    • Maximum Digging Depth: 8,200mm (26'10")
    • Maximum Reach at Ground Level: 11,730mm (38'5")
    • Maximum Cutting Height: 10,740mm (35'2")
    • Maximum Loading Height: 7,490mm (24'6")
    • Minimum Loading Height: 1,900mm (6'2")
    • Maximum Depth Cut for 2,440mm (8'0") Level Bottom: 8,060mm (26'5")
    • Maximum Vertical Wall Digging Depth: 6,360mm (20'10")
    • Bucket Digging Force: 210kN (47,160 lbf)
    • Stick Digging Force: 144kN (32,440 lbf)

  • Engine:
    • Make: CAT
    • Model: C9.3B
    • Power Output: 314HP (233kW)
    • Displacement: 9.3L (568in³)

  • Swing Mechanism:
    • Swing Speed: 8.75 RPM
    • Maximum Swing Torque: 144kN∙m (106,228 lbf-f)

  • Hydraulic System
    • Main System – Maximum Flow – Implement: 558 L/min (279L × 2 Pumps) 147 Gal/min (74Gal × 2 Pumps)
    • Maximum Pressure – Equipment – Implement: 35,000 kPa (5,076 PSI)
    • Maximum Pressure – Equipment – Lift Mode: 38,000 kPa (5,511 PSI)
    • Maximum Pressure – Travel: 35,000 kPa (5,076 PSI)
    • Maximum Pressure – Swing: 29,400 kPa (4,264 PSI)

  • Overall Dimensions:
    • Shipping Height (Top of Cab): 3,170mm (10'4")
    • Shipping Length: 11,200mm (36'8")
    • Tail Swing Radius: 3,530mm (11'6")
    • Counterweight Clearance: 1,250mm (4'1")
    • Ground Clearance: 510mm (1'8")
    • Track Length: 5,030mm (16'6")
    • Track Length to Center of Rollers: 4,040mm (13'3")
    • Track Gauge – Long Undercarriage: 2,590mm (8'5")
    • Operating Weight: 37,200 Kg (81,900 lbs.)

  • Location: Eastern USA
