• Engine:
    • Make: Caterpillar.
    • Model: 3412.
    • Gross Power: 682.6 hp (509 kw).
    • Net Power: 650.4 hp (485 kw).
    • Power Measured @ 2000 rpm.
    • Displacement: 1647.6 cu in (27 L).
    • Aspiration: turbocharged and aftercooled.
  • Operational:
    • Fuel Capacity: 184.9 gal (700 L).
    • Cooling System Fluid Capacity: 39.9 gal (151 L).
    • Engine Oil Capacity: 18 gal (68 L).
    • Diff and Final Drive Fluid Capacity: 40.9 gal (155 L).
    • Steering System Fluid Capacity: 21.4 gal (81 L).
    • Operating Voltage: 24V.
    • Tire Size: 21.00-35 32PR (E-3).
  • Transmission:
    • Number of Gears - Forward: 7.
    • Number of Gears - Reverse: 1.
    • Max Speed: 35.6 mph (57.3 km/h).
  • Weights:
    • Empty Weight: 86853.3 lb (39396 kg),
    • Loaded Weight  204002.6 lb (92534 kg).
    • Weight Distribution Front - empty: 47.3 %.
    • Weight Distribution Rear - empty: 52.7 %.
    • Weight Distribution Front - loaded: 33.3 %.
    • Weight Distribution Rear - loaded: 66.7 %.
  • Dump:
    • Rated Payload: 119000 lb (53977.5 kg).
    • Load Capacity - Struck: 34 yd3 (26 m3).
    • Load Capacity - heaped 44.6 yd3 (34.1 m3).
    • Dump Angle: 54.5 degrees.
    • Raise Time: 11.4 sec.
    • Lower Time: 14.2 sec.
  • Dimensions:
    • Overall Length: 30.4 ft in (9270 mm).
    • Overall Width: 15.4 ft in (4700 mm).
    • Overall Height: 13.9 ft in (4230 mm).
    • Wheelbase: 13.7 ft in (4190 mm).
    • Ground Clearance: 1.9 ft in (580 mm).
    • Dump Height: 28.4 ft in (8660 mm).
    • Dump Ground Clearance: 1.9 ft in (580 mm).
  • Quantity: 11.
