48 inch wide x 23 foot long Cedarapids Belt Feeder ID: 144718

Need this? Click here    Have one? Click here
  • Cedarapids 35 Yard Belt Feeder.
    • Hopper Dimensions:
      • 20' long x 9' wide x 8' high.
    • Belt Dimensions:
      • 48" wide x 23' long
    • 18” diameter rubber lagged head pulley.
    • Self-cleaning tail pulley.
    • 5” diameter rubber impact rollers.
    • On 10.5” centers.
    • 6” diameter return rollers.
    • ½” thick 4 ply belting.
    • Dodge TXT625 shaft mount reducer
  • Whole unit mounted on 12” X 5” I-Beam frame.
    • With channel skid and 3” x 3” angle cross bracing.
  • Hopper comes off feeder for transport
  • Would need 2 trucks to ship
  • Over all dimensions of feeder
    • 23 ft. long
    • 9 ft. x 10 in. wide
    • 5 ft. x 9 in. high
  • Over all dimensions of hopper
    • 23 ft. long
    • 9 ft. x 6 in. wide
    • 10 ft. high

Please contact us for additional information.

Sold
