• Engine:
    • Make: Caterpillar.
    • Model: 3412E.
    • Gross Power: 710 hp (529.4 kw).
    • Net Power: 671 hp (500.4 kw).
    • Power Measured @ 2000 rpm.
    • Displacement: 1649 cu in (27 L).
    • Max Torque: 2532.8 lb ft (3434 Nm).
  • Operational:
    • Fuel Capacity: 185 gal (700.3 L).
    • Cooling System Fluid Capacity: 40 gal (151.4 L).
    • Engine Oil Capacity: 18 gal (68.1 L).
    • Diff and Final Drive Fluid Capacity: 41 gal (155.2 L).
    • Steering System Fluid Capacity: 16 gal (60.6 L).
    • Brake/Hoist System Fluid Capacity: 81 gal (306.6 L).
    • Tire Size: 24.00-R35 (E4).
  • Transmission:
    • Number of Gears - Forward: 7.
    • Number of Gears - Reverse: 1.
    • Max Speed: 41.1 mph (66.1 km/h).
  • Weights:
    • Empty Weight: 66500 lb (30163.9 kg).
    • Loaded Weight: 219000 lb (99336.7 kg).
    • Weight Distribution Front - empty: 47.3 %.
    • Weight Distribution Rear - empty: 52.7 %.
    • Weight Distribution Front - loaded: 33.3 %.
    • Weight Distribution Rear - loaded: 66.7 %.
  • Dump:
    • Rated Payload: 119622.8 lb (54260 kg).
    • Load Capacity - Struck: 34.8 yd3 (26.6 m3).
    • Load Capacity - heaped: 46 yd3 (35.2 m3).
  • Dimensions:
    • Overall Length: 30.2 ft in (9207 mm).
    • Overall Width: 14.6 ft in (4457 mm).
    • Overall Height: 14.5 ft in (4424 mm).
    • Wheelbase: 13.8 ft in (4191 mm).
    • Ground Clearance: 2.2 ft in (667 mm).
    • Dump Height: 28.9 ft in (8815 mm).
    • Dump Ground Clearance: 2.2 ft in (667 mm).
  • Quantity: 4.

View more Rock Trucks

Sold

Image 1 of 2

Manufacturer:CATERPILLAR

CATERPILLAR
