- 600A vertical.
- 600A horizontal.
- Bucket 1:
- GE size 3 starter - 120 coil.
- Overload: 123F467B.
- GE 100A breaker - adjustable trip.
- Bucket 2 & 4:
- GE size 2 starter - 120 coil.
- Overload = C21.4B.
- 100VA control transformer - 600/120V.
- GE 50A breaker - adjustable trip.
- Buckets 3:
- GE size 1 starter - 120 coil.
- Overload: C6.30A.
- 100VA control transformer - 600/120V.
- GE 7A breaker - adjustable trip.
- Bucket 5:
- GE size 1 starter - 120 coil.
- Overload: C1.96A.
- 100VA control transformer - 600/120V.
- GE 7 amp breaker - adjustable trip.
- Dimensions (Single section) L x W x H:
- 20 in. x 20 in. x 94 in.
- 51 cm x 51 cm x 239 cm.
